The DJI Goggles are comfortable goggles designed fir seamless FPY flying with DJI products.  They combine a pair of large ultra-high quality screens, long-range, low lag wireless connectivity, and direct control of photo and video capture. With Intelligent Flight Modes like ActiveTrack, TapFly, Terrain Follow, Cinematic Mode and Tripod mode, a totally new flying dimension is created.
No Latticing: Each screen packs its pixels together tightly so you see a clean, cohesive image with no latticing. DJI Goggles can be used non-stop for a maximum of six hours.
High Resolution: Typical “2K” screens inside the goggles are split into two 1280x1440 sections, one for eye. When viewing a 16:9 image, some sections are further cut off, leaving only a quarter of the available pixels. DJI Goggles have two 1920x1080 screens providing more than twice the amount of pixels of a typical 2K single screen.
Optical Design: DJI Goggles use a beam splitter to display an image in front of each eye, as well as polarization to prevent any image overlap. This allows it to create genuine Full HD 1920x1080 resolution per eye. When used with the large aperture aspheric lens, an 85° field of view per eye is created for maximum immersion.
Your head movements control both aircraft yaw and camera tilt in Head Tracking Flight mode as with remote controller sticks. All you need to do is turn left or right to yaw left or right, and straighten your head to stop turning. In Head Tracking Gimbal mode only the gimbal will move without affecting yaw.
TOUCHPAD & REMOTE CONTROLLER
Access to key intelligent features through a touchpad integrated into the DJI Goggles or 5D button on the Mavic Pro controller makes navigating the internal menu system easy and intuitive.
DJI Goggles are a perfect pair with DJI’s new Intelligent Flight Mode: Fixed-Wing Mode. In this mode, the aircraft doesn’t turn left or right but instead flies forward with enough rotational movement for realistic flight simulation. Combined with Head Tracking Mode, you can use your head to control the Mavic Pro for a fully realized flight experience. An AR trajectory prediction feature in Fixed-Wing Mode makes using this mode in complex environments safer. Other Intelligent Flight Modes include Terrain Follow. ActiveTrack, TapFly, Cinematic Mode and Tripod Mode.
COMFORTABLE AND FLEXIBLE
A unique solid headband design balances and spreads the weight of DJI Goggles around the head evenly, minimizing pressure on the face and keeping them comfortable to wear for hours. People who wear glasses are also able to wear them comfortably. The screen portion of DJI Goggles can be flipped up to glimpse the real world, or detached entirely for easy storage and portability.
A range of built-in interfaces allows DJI Goggles to work with a wide range of devices.
MICRO USB INPUT
Connect compatible Phantom 4 series and Inspire 2 using the USB port to get access to tracking functions and head tracking. Its also used fir firmware upgrades
MICRO SD CARD
Download files from the aircraft to the goggle’s onboard SD card for a backup, or view video files you have captured.
Plug headphones into the headphone jack or use the onboard speakers to listen to audio on videos being played through the HDMI cable
Watch camera feeds from a Phantom 4 series or inspire drones , or plug in a video device to watch films or play games.
What is the correct way to put on and wear the DJI Goggles?
the headband into the slot above the lenses until you hear a click. Check that it has been fastened securely. Align the lenses over your eyes and pull the strap down. Adjust the strap knob until the headset fits snugly and comfortably on your head.
Can I wear glasses while using the DJI Goggles kit?
Yes. The DJI Goggles can be worn over glasses.
Are the DJI Goggles water-resistant?
No, they are not.
How do I adjust the interpupillary distance (IPD) between the lenses? What pupil distance will suit me best?
First, turn the IPD knob to adjust the distance between the lenses until the images are aligned. When the images align, you will have the most suitable pupil distance for you.
How do I avoid touching the touchpad by mistake?
You can lock the touchpad by swiping backwards with two fingers.
When pressing and holding down the power button, my DJI Goggles sometimes only work sporadically. Why?
To ensure normal system functioning, the DJI Goggles will not respond to any on/off command within 10s after the last turn on/turn off.
How many DJI Goggles can be connected to one Mavic Pro drone at the same time?
Apart from pairing the DJI Goggles with a Mavic Pro drone and remote controller, there are two connection combinations: 1. One Mavic Pro Drone + two DJI Goggles + two Mavic Pro remote controllers 2. One Mavic Pro Drone + one DJI Goggles + two Mavic Pro remote controllers.
What happens when more than one pair of DJI Goggles / remote controllers are connected to the same drone?
In Coach mode, only the master remote controller can change the flight mode. The drone starts to respond to the slave remote controller only when the master remote controller doesn’t give any commands for more than two seconds. The master remote controller can override anytime. In Dual Operation Mode (one drone + two DJI Goggles + two remote controllers), the slave DJI Goggles will not support Head Tracking Mode. If the remote controller and DJI Goggles are being operated by the same user, a spotter who is able to give instructions and warnings is required to ensure safe flying.
What DJI drones are compatible with the DJI Goggles through USB cables?
Phantom 4, Phantom 4 Pro, Phantom 4 Advanced, and Inspire 2.
What devices can be connected with the DJI Goggles using the HDMI connector?
Any device that has an HDMI port.
What is the Micro SD Card slot on the DJI Goggles used for?
The Micro SD Card slot on the DJI Goggles is used to download files from the aircraft to the goggle’s onboard SD card for backup and to view captured video files.
Can I download videos not recorded by a drone to a Micro SD Card and then insert them into DJI Goggles to watch them?
Why is the Mavic Pro the only drone that can be connected to the DJI Goggles wirelessly?
Because of OcuSync. The same video transmission system carried by the Mavic Pro has also been integrated into the DJI Goggles, making the wireless connection between these two devices possible.
What are the main differences between HD Mode and Smooth Mode?
In HD Mode, the resolution of video transmission footage reaches 1080p/30fps for near field, lowering to 720p/30fps for far field or when affected by interference. In Smooth mode, the resolution will remain at 720p/60fps. The former is for a clear and immersive FPV experience, and the latter is for smoother FPV footage.
Why does the video transmission image quality in my DJI Goggles sometimes change?
The resolution of video transmission footage seen in the DJI Goggles changes along with the video recording resolution. Therefore: 1. When video is recorded at 4K, the highest video transmission resolution is 720p/30; 2. When video is recorded at 2.7K, video transmission resolutions tops out at 1080p/30; 3. When video is recorded at 1080p or below, depending on whether the frame rate is higher than 30fps or lower than 30fps, the max video transmission resolution will be 720p/60fps 0r 1080p/30fps, respectively.
What is the difference between the DJI Goggles 1080p screens and other 2K screens?
Typical “2K” screens inside other brands of googles are split into two 1280x1440 sections, one for each eye at 720p. The DJI Goggles are dual 1080p screens, meaning that each screen has a maximum resolution of 1920*1080.
What kind of latency is there when the DJI Goggles are connected with different devices?
HD video downlink latency (near field and free of interference) can be as low as: 110 ms (Mavic Pro, 720p60, video format: 720p120) 150 ms (Phantom 4 series, 720p60, video format 720p60/720p120) 140 ms (Inspire 2+X5S, 720p60, video format : 1080p120) 190 ms (Inspire 2+X4S, 720p60, video format 1080p60)
How do I update the DJI Goggles firmware?
There are three main ways to update firmware: 1. Directly connect your DJI Goggles to a PC. 2. Pair your remote controller, drone, and DJI Goggles before connecting the remote controller to a PC, and update all three devices together. 3. Pair your remote controller, drone and DJI Goggles, then connect the remote controller with the DJI GO app (or GO 4.0) to update the three devices simultaneously within the app.
Do the DJI Goggles offer the same functions no matter what device they’re connected to? If not, what are the main differences?
No. For specific functions according to the different devices the DJI Googles are connected to, please refer to the user manual.
Why does a drone connected to the DJI Goggles keep rotating in Head Tracking Mode even when I have already stopped moving?
In Head Tracking Mode, a drone’s yaw depends on the pilot’s head movements. If the pilot doesn’t stop where he began, the drone will keep rotating until the pilot turns his head back to the original position.
Why do the C1/C2 buttons on the Mavic Pro controller stop responding when the drone is connected to the DJI Goggles?
For ease of operation, when the Mavic Pro is connected to the DJI Goggles, the C1/C2 buttons are automatically set to the Fn/Back buttons, which function the same as on the DJI Goggles.
